Professional technology
- The tester uses a 7-inch professional color LCD screen, the Chinese menu display.
- The date and time can be set, and the calibration interface can perform the calibration of the sensor force value.
- Print test data onboard, and the test record can be saved by exporting EXCEL form through U disk.
- Set the program by the intelligent controller, display the force value and deflection value in real time.
The test principle
Apply a specified force to the center of the specified span of the needle tube (needle) supported at both ends, and measure the deflection value and load of the needle tube.
Testing standard
The instrument is in accordance with ISO 9626-2016, GB18457-2015, and GB15811-2016.
Test application
| Basic application | Suitable for the rigidity performance determination of various injection needle tube (needle). |
qualification
| metric | parameter |
| tube wall | Normal wall, thin wall, ultra-thin wall three optional |
| Nominal specifications | 0.2~3.4mm |
| Set the load | 0~100N |
| accuracy | ±0.01N |
| Loading speed | 5~1000mm / min (at a rate of 1mm / min when loaded to the set point) |
| pan | 3.5~50mm |
| accuracy | ±0.1mm |
| Toughing test | 0~5mm, accuracy:±0.01mm |
| outline dimension | 400 mm (L) × 270 mm (W) × 360 mm(H) |
| net weight | 20kg |
product configuration
| standard layout | Host, fixture, printing paper, instructions |
| Choose a piece | Multi-in-one upgrade function (sliding, injection needle piercing force, suture needle piercing force, blade sharpness and tooling fixture) |
FAQ：
What about the product quality?
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.
For our products, each instrument must be carried out 100% quality calibration and test when delivery goods. With CE certificate, we are very confident in our products, and we will pack them with safety wooden case to protect the machine when transport oversea.
What about usage of the machine?
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
We will also give your professional guidance(Product operating manual and video), each products comes with a USB flash drive which have all the details.What about warranty?
Guarantee one years( if the parts damage within one year, we can replace the part for free)
If customer need any technical support, we can help them solve their problem through email, video meeting. We also can provide door to door service, but customer need to bear the travel fees.What about standards support?
We are strictly following different international standards such as EN, ISO, ASTM, AATC, JIS, GB ect, and had been recognized by SATRA, CSA international standard agency.
